Standard Configuration:
SYNTEC CNC system I Taiwanese Y-axis Powered Turret / SYNTEC
X, Z, Y-axis Servo Motors I Hydraulic Chuck /
Taiwanese PMI, HIWIN
Ball Screw, Roller Linear Guide
Features:
• High Rigidity, Low Vibration Design: Adopts a
30-degree slant bed saddle
structure, with the entire machine optimized through
finite element analysis
and a rational arrangement of internal bed ribs.
• Equipped with a hardened power turret, the
machine integrates compound
functions such as turning, milling, drilling, and
tapping. Combined with Caxis,
it effectively reduces product processing time and
labor, while avoiding
errors caused by secondary clamping of workpieces .
• Equipped with reinforced P3-class ball screws and
roller linear guides, the
Z-axis adopts a configuration with six sliders.
• Available with programmable hydraulic tailstock or
programmable servo
tailstock.
