Performance Features:

◆ Adopting high-strength body structure, with small deformation and high accuracy.
◆ The slider adopts a hexagonal guide path with two corners, and the slider guide adopts a "high-frequency quenching" and "rail grinding process," which has low wear, high accuracy, long accuracy retention time, and improved mold service life.
◆ The crankshaft is made of high-strength alloy material 42CrMo, which is 1.3 times stronger than 45 steel and has a longer service life.
◆ The copper sleeve adopts tin phosphorus bronze 205n10-1, which has a strength 1.5 times higher than ordinary BC6 brass.
◆ Adopting a highly sensitive hydraulic overload protection device can effectively protect the service life of the punching machine and mold.
◆ Equipped with bearings and Japanese NOK seals as standard.
◆ Standard imported 15.6-inch touch screen. Optional mold pad (air cushion).

◆ Built-in 9 processing modes, each product can choose the most suitable processing curve for component processing, achieving high precision, high efficiency, and high energy conservation.
◆ Compared with traditional punching machines, it has the characteristics of simple structure, high mechanical transmission efficiency, and low maintenance cost.
◆ According to the characteristics of the product/material, the forming speed of the punch can be reduced during material processing to achieve the optimal forming speed of the product/material. This reduces vibration and stamping noise, improves product accuracy, and extends the service life of the mold.
◆ According to different products and different heights, the stroke of the punching machine can be set arbitrarily, greatly shortening the stamping time and improving efficiency.
